E-BIKE FRAME
Guide: > Products > E-BIKE FRAME >

  • SPEC
  • FEATURES
  • GEOMETRY

 27.5ER PLUS FULL HIDDEN E-BIKE FRAME M09 FOR BAFANG MOTOR



Use for: 27.5er Plus E-Bike

Frame:  M09 BAFANG

Feature: Thru Axle (148mm)

Material: full Toray carbon

Finish: UD Matt/Clear coating

Frame weight: 2800±50g (17.5")

Headset: Tapered 1-1/8" to 1-1/2" (OD 51/62mm/ ID 44/56mm)

Frame travel: 135-152mm

Available sizes: 15.5"/17.5"/19.5"/21"

Tire size: 27.5er*2.4"/2.6"/2.8" or 29er*2.3"/2.6"/2.7"

Warranty: 2 years

Related Products :

  • Name: M09 BAFANG
  • Model:
  • Download SGS:Download
SPEC

 27.5ER PLUS FULL HIDDEN E-BIKE FRAME M09 FOR BAFANG MOTOR



Use for: 27.5er Plus E-Bike

Frame:  M09 BAFANG

Feature: Thru Axle (148mm)

Material: full Toray carbon

Finish: UD Matt/Clear coating

Frame weight: 2800±50g (17.5")

Headset: Tapered 1-1/8" to 1-1/2" (OD 51/62mm/ ID 44/56mm)

Frame travel: 135-152mm

Available sizes: 15.5"/17.5"/19.5"/21"

Tire size: 27.5er*2.4"/2.6"/2.8" or 29er*2.3"/2.6"/2.7"

Warranty: 2 years

FEATURES
GEOMETRY
